2-step LED Indicator Display

2 Color LED display shows the charge status of the battery. Red indicates recharging while green indicates fully charged.

Exchangeable Power Plugs

With exchangeable international ( Eu-Euro, US-America, UK-United Kingdom) power plugs, the travel sized RP-DC30 can be used world-wide.
Just simply use the appropriate snap-in supplied power plug model, with respect to the AC power standard you are located in, and begin charging your batteries.

Charging Technology

Intelligent charging systems integrate the control systems within the charger and the electronics within the battery to allow precise control over the charging process. As a safety precaution with high-capacity batteries, a pre-charging stage is used. The charging cycle is initiated with a low current. If there is no corresponding rise in the battery voltage, it indicates that there is possibly a short circuit in the battery (zero volt activation). Constant current/constant voltage (CC/CV) charging mode is an effective way to charge lithium batteries. When a lithium battery is nearly empty, we take constant current to charge it. Charger CPU automatically adjusts charging current to be lower than the max charging current that the battery can accept. With constant charging, the voltage of the battery rises slowly until it reaches a maximum voltage at which point the charger switches the charging method to “constant voltage” and reduces the charging current. When the battery is fully charged, this state is stopped.

In Car Use

With a 12V-24V DC power source (DC 12V car charger sold separately) you can use the charger in a car, plane, bus or any location with a 12V-24V DC power supply.

Interchangeable Battery Plates

With easily interchangeable battery plates, the intelligent charger can be used for all world brand battery models.

This economical option of interchangeable plates allows you to charge many different types of batteries, all with one charger. The charger automatically sets charging voltage and charging current for the designed battery. This leaves no space for charging error!

NOTE: Battery Plates Sold Separately

Battery Plate Finder

Design made in Switzerland

With R&D (research & developing) department located in Switzerland – Europe, Hedbox team has an innovative approach to battery and power management product design.

Eco-Green Consistency

All materials used in HEDBOX Products meet the highest eco-green requirements. Actively protecting the environment and preserving the highest standards of environmental protection.

Worldwide Distribution

With established distribution centers in the United States, Europe, the Middle East, and Asia, the company has organized fast and secure delivery of its products to customers around the world.

IATA Transport Regulations

All HEDBOX warehouses around the world are trained and certified according to the latest IATA guidelines. This enables safe packaging and preparation for the transport of all our products worldwide via AIR Road and Sea.

Interested in this product ... ? Want to buy ... ? Please click here ... Find a store near you

Tech specifications

Model :RP-DC30 Traveler Battery Charger
AC Power In : AC 110 – 240V , 50/60Hz
DC Power In :DC 12V
Power Consumption :Max 35W
Power Output :DC 3.6V – 8.4V. 800 mA (Max) (auto-change the voltage according to the installed optional charging plate)
DC Power Input :DC 12V / 25W
Charging Type :Ni-CD , Ni-MH , Li-Ion
Operating Temperature :–20°C to +45°C (–4°F to +113°F)
Dimensions (WxDxH) :90 x 50 x 35 mm
Weight :85 g
Charging Method :RP-DC30 use optional changing plates according to the Battery Pack Manufacturer and Model



Supported products

Package includes

Under transport regulation, the RP-DC30 is factory packed in a cardboard box with internal shock resistance protection. This kind of packaging makes it travel and transportation safe for the Sea, Air and Road.
The Cardboard box is suitable for use in Retail Shops (hang on hole support).

  • 1 x RP-DC30 Battery Charger
  • 1 x AC Power US Plug
  • 1 x AC Power UK Plug
  • 1 x AC Power EU Plug
  • 1 x 12V DC Car Power Cable
  • 1x QR Code Card - User Manual
  • 1 x 2 Year Limited Warranty
  • Battery Plate NOT INCLUDED IN THE BOX it need to be ordered separately
1 x RP-DC30 Battery Charger
1 x AC Power US Plug
1 x AC Power UK Plug
1 x AC Power EU Plug
1 x 12V DC Car Power Cable
